Experience high-powered versatility
Add dynamic capabilities to meet new demands
Expedite everyday workloads
Work your way, every day
Add uptime with smarter support
*When enabled, internet connection required.
Stay productive on the move
Add the finishing touch
Account for everything
Consume less energy, conserve more cash
Need more information?
Configuration | Console |
---|---|
Printing Process | Dry, two component & electro-photographic |
Control Panel | 10.1" Smart Operation Panel |
Output Speed Copy/Print | 80 ppm |
First Page Out Time | 4.7 seconds |
Warm-Up Time | 20 seconds |
Resolution | 600 x 600 dpi |
System Memory | 2 GB RAM + 320 GB Hard Disk Drive (standard/maximum) |
Maximum Copy Quantity | Up to 999 copies |
Duplexing | Automatic (Standard) |
Zoom Range | From 25% to 400% in 1% steps |
Supported Paper Sizes | Letter, Legal, Ledger, A3, A5, A6, B4, B5, B6 |
Supported Paper Weights | Trays: 52 - 256 g/m2 Bypass: 52 - 300 g/m2 Duplex: 64 - 256 g/m2 |
Supported Paper Types | Plain, Recycled, Special, Color, Letterhead, Preprinted, Bond, Label |
Standard Paper Capacity | Standard: 4,300 sheets Bypass: 100 sheets |
Maximum Paper Capacity | 8,700 sheets |
Standard Output Capacity | 500 sheets |
Maximum Output Capacity | 3,500 sheets |
Power Source | 120-127V/20A 60Hz |
Typical Electricity Consumption (TEC) | 1.696 kWh/week |
Power Consumption | Less than 2,100 W; Sleep Mode: 0.6W |
EPEAT Status | Gold |
Dimensions W x D x H | 27.17" x 34.76" x 45.71" (690 x 883 x 1161 mm) |
Weight | 441 lbs. (200 kg) |
64 MB Fax Memory Unit Type M25
ID: 417644
- Memory expansion, which provides additional 64 MB memory for facsimile functions.
Notes:
- Fax Option Type M25 and G3 Interface Unit Type M25 options are required.
Booklet Finisher SR4160
ID: 418180
- The 2,000-sheet Booklet Finisher allows thick documents to be professionally finished as paginated, duplexed, saddle-stitched folded booklets.
- Up to 20 sheets can be saddle-stitched.
- It also offers 65-sheet, multi-position stapling, mixed sized stapling, optional hole-punching and shift-sort collating.
- Weight: 127.9 lbs. (58 kg)
- W × D × H (inches): 25.87 × 28.74 × 38.59
- W × D × H (mm): 657 × 730 × 980
Notes:
- Booklet Finisher SR4160 cannot be installed with Copy Tray Type 9002, Finisher SR4150 or any related options.
Copy Tray Type 9002
ID: 416229
- Select the 500-sheet Copy Tray if you do not require advanced finishing including stapling, hole punching, folding or booklet making.
- When configured with this option, output is delivered face down in a neat stack.
- Weight: 1.65 lbs. (.75 kg)
- W x D x H (inches): 12.9 x 16.2 x 3.1
- W x D x H (mm): 328 x 411 x 79
Notes:
- Copy Tray Type 9002 cannot be installed with Finisher SR4120, Booklet Finisher SR4130, Finisher SR4080, Cover Interposer Tray CI4030, Cover Interposer Tray CI4040, Mailbox CS4010, Multi-Folding Unit FD4000, or any related options.
Finisher SR4150
ID: 418178
- This 3,000-sheet Finisher is ideal for offices that produce collated and stapled sets of documents. It offers 65-sheet, multi-position stapling, mixed sized stapling, optional hole-punching and shift-sort collating.
- Weight: 83.8 lbs. (38 kg)
- W × D × H (inches): 25.87 × 28.74 × 38.58
- W × D × H (mm): 657 × 730 × 980
Notes:
- Finisher SR4150 cannot be installed with Copy Tray Type 9002, Booklet Finisher SR4160 or any related options.
Mail Box CS4010
ID: 416633
- The 9-Bin Mailbox offers workgroups the ability to separate and stack document output to designated bins directly from the print driver. This option helps keep workflows streamlined and organized.
- Weight: 33 lbs. (15 kg)
- W x D x H (inches): 21.26 x 23.62 x 25.98
- W x D x H (mm): 540 x 600 x 660
Notes:
- 1. One of the following finishers is required: SR4150 or Booklet Finisher SR4160.
- 2. Mail Box CS4010 cannot be installed with Copy Tray Type 9002
Multi-Fold Unit FD4020
ID: 418185
- Provides automatic inline document folding with the ability to deliver folded output in six different patterns; Half-Fold, Letter Fold‑In (Tri-Fold), Letter Fold-Out (Tri-Fold), Gate-Fold, Double Parallel Fold (Four-Fold) and Z-Fold. The Multi-Folding Unit is ideal for companies that want to produce professionally finished documents such as newsletters, brochures, menus and marketing materials in-house.
- Power Requirements: 120V, 60Hz, 15A
- Weight: 202.82 lbs. (92 kg)
- W × D × H (inches): 18.5 × 27.74 × 38.58
- W × D × H (mm): 470 × 705 × 980
Notes:
- 1. Finisher SR4150 or Booklet Finisher SR4160 must be selected to add this option.
- 2. Multi-Fold Unit FD4020 cannot be installed with Copy Tray Type 9002 or any related options.
Output Jogger Unit Type M25
ID: 417630
- Aligns and stacks output delivered to Finisher SR4150 or Booklet Finisher SR4160.
Punch Unit PU3090 NA
ID: 418332
- Optional hole punching for the Finisher SR3280.
- Supports paper sizes up to 11" x 17".
IEEE 802.11a/g/n Interface Unit Type M19
ID: 417493
- This option allows you to connect the device to an IEEE 802.11 a/b/g/n wireless LAN.
OCR Unit Type M13
ID: 417430
- This function embeds invisible text on scanned images of PDF and enables users to search PDF files by arbitrary keywords. Searchable PDF files can be sent to email, folders, and external media (USB/SD Card).
Optional Counter Interface Unit Type M12
ID: 417111
- 20-Pin interface used to attach external key counter or key card device.
Smart Card Reader Built-in Unit Type M19
ID: 417595
- For use with Ricoh & third party software solutions. The smart card reader and its cable will be covered inside the mainframe when this option is attached. Not all card readers may be supported.
