| Projection System | Single Chip Digital Light Processing (DLP) |
|---|---|
| Resolution | Up to WUXGA@60Hz (Reduced Blanking) & UXGA@60Hz |
| Liquid Crystal Panel Size | 0.67" |
| Aspect Ratio | 16:10 |
| White Light Output Brightness | 6,000 lm |
| Color Reproduction | 1.07 billion colors |
| Contrast Ratio | 1200:1 (100000:1) |
| Screen Size | 50" - 300" |
| Projection Modes | Standard, Rear, Ceiling, Rear Ceiling |
| Lamp Type | Laser diodes |
| Lamp Life | Up to 20,000 hours |
| Projection Lens | 6 optional bayonetted lenses available. See listing in Accessories |
| Lens Shift/Method | Motorized Vertical (+/- 100%) and Horizontal (+/- 30%) |
| Zoom / Focus | Motorized |
| Keystone Vertical/Horizontal | +/- 20 degrees |
| Scan Rate | Horizontal: 15-91.1KHz; Vertical: 24-85Hz |
| Connection Terminals | HDBaseT x 1 HDMI x 1 Computer In x 1 Monitor Out x 1 DVI-D x 1 USB Type A x 1 YPBPR x 1 PC Control (D-sub 9 pin) x 1 Wired In/Out (3.5mm phone jack) x 1 LAN (RJ45) x 1 Service x 1 |
| Image Input | HDTV 720p (50/60Hz), 1080i/p (50/60Hz), 1080p (24/25/30/50/60Hz), SDTV 480i/p, 576i/p |
| Supported Utilities | PJ Link and Crestron® AV management software |
| Features | 360° Free Tilt Free, Picture-in-Picture, Picture-by- Picture, Pincushion, Portrait Mode, Security Bar, Kensington Lock, 3D Projection(Frame sequential XGA/720p only), Eco Mode, Firmware Update |
| Dimensions W x D x H | 19" x 20" x 7.3" (484 x 509 x 185mm) |
| Weight | 39.6 lbs. (18 kg) (not including lens) |
| Fan Noise | Standard Mode: 35 dB; Eco Mode: 33 dB |
| Power Supply | 100/240V; 50 - 60Hz |
| Power Consumption | Standard Mode: 560W; Eco Mode: 340W or less |
| Whats In the Box | CD-ROM with user manual, RGB cable, Power cord, Warranty sheet and registration (USA only), Remote control and batteries, lens mount cover |
Replacement Lens Type A1 (Short Throw)
ID: 512914
- Focal Length: 11.11 – 14.06
- F Number: 2.30 – 2.53
- Focus Spec (MTF): 67 lp/mm
- Zoom Range (Ratio): 1.26X
- Zoom and Focus Adjustment: Motorized
- Throw Ratio for PJ WXL6280: 0.79 – 1.00
- Throw Distance for PJ WXL6280: ) 33" – 254" (0.83 – 6.45 m)
- Throw Ratio for PJ WUL6280: 0.75 – 0.95
- Throw Distance for PJ WUL6280: m) 32" – 241" (0.81 – 6.13 m)
- Projection Image Size (Diagonal): 50 – 300 inch
Replacement Lens Type A2 (Wide Zoom)
ID: 512915
- Focal Length: 14.03 – 17.96
- F Number: 2.30 – 2.57
- Focus Spec (MTF): 67 lp/mm
- Zoom Range (Ratio): 1.28X
- Zoom and Focus Adjustment: Motorized
- Throw Ratio for PJ WXL6280: 1.00 – 1.28
- Throw Distance for PJ WXL6280: 43" – 326" (1.08 – 8.27 m)
- Throw Ratio for PJ WUL6280: 0.95 – 1.22
- Throw Distance for PJ WUL6280: 40" – 310" (1.02 – 7.88 m)
- Projection Image Size (Diagonal): 50 – 300 inch
Replacement Lens Type A3 (Standard)
ID: 512916
- Focal Length: 18.07 – 22.59
- F Number: 2.00 – 2.32
- Focus Spec (MTF): 47 lp/mm
- Zoom Range (Ratio): 1.25X
- Zoom and Focus Adjustment: Motorized
- Throw Ratio for PJ WXL6280: 1.28 – 1.61
- Throw Distance for PJ WXL6280: 54" – 409" (1.38 – 10.4 m)
- Throw Ratio for PJ WUL6280: 1.22 – 1.53
- Throw Distance for PJ WUL6280: 52" – 389" (1.31 – 9.89 m)
- Projection Image Size (Diagonal): 50 – 300 inch
Replacement Lens Type A4 (Long Zoom)
ID: 512917
- Focal Length: 22.56 – 42.87
- F Number: 2.30 – 3.39
- Focus Spec (MTF): 67 lp/mm
- Zoom Range (Ratio): 1.9X
- Zoom and Focus Adjustment: Motorized
- Throw Ratio for PJ WXL6280: 1.60 – 3.07
- Throw Distance for PJ WXL6280: 68" – 781" (1.72 – 19.84 m)
- Throw Ratio for PJ WUL6280: 1.52 – 2.92
- Throw Distance for PJ WUL6280: 65" – 743" (1.64 – 18.87 m)
- Projection Image Size (Diagonal): 50 – 300 inch
Replacement Lens Type A5 (Ultra-Long Zoom)
ID: 512918
- Focal Length: 42.60 – 80.90
- F Number: 2.30 – 2.74
- Focus Spec (MTF): 67 lp/mm
- Zoom Range (Ratio): 1.9X
- Zoom and Focus Adjustment: Motorized
- Throw Ratio for PJ WXL6280: 3.04 – 5.78
- Throw Distance for PJ WXL6280: 129" – 1,470" (3.27 – 37.35 m)
- Throw Ratio for PJ WUL6280: 2.90 – 5.50
- Throw Distance for PJ WUL6280: 123" – 1,399" (3.12 – 35.54 m)
- Projection Image Size (Diagonal): 50 – 300 inch
