Maintenance & Parts
| Replacement Lamp - Part Number | 512624 Note: Lamps are consumable products and therefore are not covered by the projector’s warranty. |
|---|---|
| Projection System | 3LCD technology |
| Resolution | XGA - 1024 x 768 dpi |
| Liquid Crystal Panel Size | 0.59" |
| Aspect Ratio | 16:10 |
| White Light Output Brightness | 4,500 lm |
| Contrast Ratio | 4000:1 with iris |
| Screen Size | 25" - 300" |
| Projection Distance | 27" - 573" |
| Lamp Type | Mercury |
| Lamp Life | Standard Mode 3,500 hours; Eco Mode 1 4,000 hours; Eco Mode 2 6,000 hours |
| Zoom Ratio | 1: 1.7 or 1 |
| Zoom / Focus | Manual/Manual |
| Video Compatible Signal | NTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL-60 |
| Analog RGB Compatible Scanning Frequency | Horizontal: 24 - 100KHz Vertical: 50 - 120Hz |
| Image Input | D-SUB 15-pin x 1, RCA x 1, S-VIDEO x 1, HDMI type A x 2 |
| Image Output | D-SUB 15-pin x 1 |
| Audio Input | 3.3mm Stereo Mini-pin Jack x 1, RCA (L/R) x 1, Microphone Mini-pin Jack x 1 |
| Audio Output | 3.5mm Stereo L/R Mini-pin Jack x 1 |
| USB | TYPE-A x 1 (USB 2.0 High-Speed) for Wireless LAN, keyboard, mouse, memory, TYPE-B x 1 for USB display |
| Wired LAN | RJ45 (10BASE-T/100BASE-TX x 1) |
| Wireless LAN | Optional IEEE802.11b/g/n compliant |
| Advanced Network Utility | Windows 7 (32-bit), Windows Vista (32-bit),Windows XP SP3 or later (32- bit) |
| JPEG Conversion Tool | Windows XP SP3 or later (32- bit) Professional Edition, Windows Vista SP2 (32-bit) Ultimate, Business, Home Basic, Home Premium, Enterprise, Windows 2000 (32-bit) Professional Edition, Windows 7 (32-bit) Ultimate, Professional, Windows 7 (64-bit) Ultimate SP1, Professional SP1, Enterprise SP1, Home Premium |
| Projector Management Utility | Windows XP SP3 or later (32- bit) Professional Edition, Windows Vista (32-bit) Ultimate, Business, Windows Vista (64-bit) Ultimate SP2, Enterprise SP2, Business SP2, Home Premium SP2, Home Basic SP2, Windows 7 (32-bit) Ultimate, Professional, Windows 7 (64-bit) Ultimate SP1, Professional SP1, Enterprise SP1, Home Premium SP1, Windows 2000 (32-bit) Professional Edition |
| Built-in Speaker | 16W Mono |
| Dimensions W x D x H | 15.6" x 10.8" x 5" (398 x 276 x 127 mm) |
| Weight | 9.46 lbs. (4.3 kg) |
| Fan Noise | Standard/Eco Mode 1/Eco Mode 2: 37/30/29 dB |
| Operating Environment | Temperature 10 ~ 50° C; Humidity: 20 ~ 80% |
| Power Consumption | Standard/Eco Mode 1/Eco Mode 2 - 374W/304W/260W: Standby Network On: 2.4W; Standby Network Off: 0.2W |
