| Replacement Lamp - Part Number | 512893 Note: Lamps are consumable products and therefore are not covered by the projector’s warranty. |
|---|---|
| Wireless Lan Unit | Part # 431072 |
| Projection System | 3 LCD Technology |
| Resolution | WXGA - 1280 x 800 dpi |
| Liquid Crystal Panel Size | 0.76” |
| Aspect Ratio | 16:10 |
| White Light Output Brightness | 6,700 lm (standard lens) |
| Color Reproduction | HDMI/DisplayPort input: 1.07 billion colors Viewer/Network/VGA input: 16.77 million colors |
| Contrast Ratio | 6,000:1 |
| Screen Size | 30" - 300" |
| Projection Modes | Standard, Rear, Ceiling, Rear Ceiling, Portrait |
| Lamp Type | High-pressure mercury (Standard Mode: 350W; Eco Mode: 264W |
| Lamp Life | Standard Mode: 3,000 hours; Eco Mode: 4,000 hours |
| Projection Lens | 6 optional bayonetted lenses available. See listing in Accessories |
| Lens Shift/Method | Vertical and Horizontal/Manual |
| Zoom / Focus | Manual/Manual |
| Video Compatible Signal | NTSC, PAL, PAL60 SECAM, HDMI, HDMI 3D, HDCP |
| Analog RGB Compatible Scanning Frequency | Horizontal: 15 – 108KHz (RGB 24KHz - 10KHz); Vertical: 48 – 120Hz |
| Connection Terminals | Analog Video Input: Mini D-Sub 15-pin x 1, 5-pin BNC x 1 Analog Audio Input: Stereo Mini-pin Jack x 2 (1 each for use with VGA or BNC input) Digital Video Input: HDMI x 2, DisplayPort x 1 Monitor Output: HDMI x 1 Audio Output: Stereo Mini Jack x 1 3D Synch Output: Mini DIN 4-pin x 1 (for synchronized 3D output with option) Wired Network: 10/100BASE-TX Ethernet x 1 (RJ-45) Wireless LAN: Optional IEEE802.11b/g/n USB Ports: USB 2.0 Type A x 1 (rear port for flash drive or keyboard; USB 2.0 Type A x 1 (side port for USB wireless LAN Unit) PC Control: Mini D-Sub 9-pin x 1 Remote Connector: Stereo Mini Jack x 1 (for service use) |
| Wireless LAN | Optional: IEEE 802.11 a/b/g/n compliant |
| Projector Management Utility | Windows 7/Vista/8/8.1 |
| Supported Utilities | Projection Utility for Windows; Projection Utility for Mac (10.6 and later); Advanced Network Utility Software (Windows only), JPEG Conversion Utility Software (Windows only); Projector Management Utility (Windows only) |
| Features | 360° Free Tilt, Auto Adjust, Blank/Mute/AV Mute, Carbon Meter, Closed Captioning, Control Panel Lock, DICOM Simulation, Digital Zoom (4 steps), Eco Mode, Edge Blending, Freeze, Geometric Picture, Picture-by-Picture, Portrait Projection, Remote Desktop, Security Bar, Security Keyword, Simultaneous MultiProjection, USB Projection, Wall Color Mode, Wired/Wireless Network Projection |
| Built-in Speaker | 10W Mono |
| Dimensions W x D x H | 19.6" x 14.1" x 5.6" (499 x 359 x 142 mm) |
| Weight | 18.5 lbs. (8.4 kg) (not including lens) |
| Fan Noise | Standard Mode: 38 dB; Eco Mode: 31 dB |
| Power Supply | 100/240V; 50 - 60Hz |
| Power Consumption | Standard Mode: 483W; Eco Mode: 377W or less; Standby: Less than 1W |
| Whats In the Box | CD-ROM with user manual, JPEG conversion software, network utility and projector management utility; Quick set up guide, RGB cable, Power cord, Warranty sheet and registration, Remote control and batteries |
Replacement Lens Type 1 (Fixed Short Throw Lens)
ID: 308935
- Screen Size (Performance Guarantee Range): 40 – 150 inch (60 – 150 inch)
- Light Output for PJ WX6181N/PJ WU6181N: 4,700lm/4,200lm
Replacement Lens Type 2 (Zoom Lens)
ID: 308936
- Screen Size (Performance Guarantee Range): 30 – 500 inch (40 – 200 inch)
- Light Output for PJ WX6181N/PJ WU6181N: 5,000lm/4,600lm
- Zoom Ratio: 1.3
Replacement Lens Type 3 (Zoom Lens)
ID: 308937
- Screen Size (Performance Guarantee Range): 60 – 500 inch (60 – 200 inch)
- Light Output for PJ WX6181N/PJ WU6181N: 5,100lm/4,700lm
- Zoom Ratio: 1.6
Replacement Lens Type 4 (Zoom Lens)
ID: 308938
- Screen Size (Performance Guarantee Range): 60 – 500 inch (80 – 200 inch)
- Light Output for PJ WX6181N/PJ WU6181N: 5,000lm/4,600lm
- Zoom Ratio: 1.52
Replacement Lens Type 8 (Short Throw Zoom Lens)
ID: 512894
- Screen Size (Performance Guarantee Range): 60 – 500 inch (80 – 200 inch)
- Light Output for PJ WX6181N/PJ WU6181N: 6,400lm/5,900lm
- Zoom Ratio: 1.3
Standard Lens Type 1 (Zoom Lens)
ID: 308934
- Screen Size (Performance Guarantee Range): 40 – 500 inch (40 – 200 inch)
- Light Output for PJ WX6181N/PJ WU6181N: 6,700lm/6,200lm
- Zoom Ratio: 2.0
Wireless LAN NP02LM2
ID: 431072
- Optional IEEE 802.11 b/g/n wireless network connectivity
