| Configuration | Desktop |
|---|---|
| Printing Process | Fully automatic one-drum press cylinder system (standard black drum included) |
| Copying Speed | User adjustable: 80, 100, 130 cpm |
| Image Modes | Letter, Photo, Letter/Photo Auto Separation, Pencil, Tint |
| Pixel Density | Master Making: 300 dpi x 300 dpi (normal mode) Scanning: 600 dpi x 600 dpi (normal mode) Master Making: 300 dpi x 400 dpi (fine mode)* Scanning: 600 dpi x 600 dpi (fine mode)* |
| Original Size | Sheet/Book: Max. 11.7" x 17" (297 mm x 432 mm) |
| Supported Paper Sizes | Max. 11.7" x 16.5" (297 mm x 420 mm); Min. 3.5" x 5.5" (90 mm x 140 mm) |
| Supported Paper Weights | 12.5 lb. Bond to 110 lb. Index (47.1 to 209.3 g/m2) |
| Printing Area | 8.3" x 14" (based on “LG†drum) |
| Leading Edge Margin | 5 mm +/- 3 mm (0.2" +/- 0.12") |
| Image Position | Vertical: +/- 10 mm (+/- 0.4") Horizontal: +10 mm (0.4") |
| First Copy Time | 33 seconds (in landscape only, using the exposure glass) |
| Spot Color | Selection of colors using optional replacement color drum |
| Reproduction Ratio | 4 reduction: 93%, 77%, 74%, 65% 3 enlargement: 121%, 129%, 155% |
| Paper Feed/Delivery Capacity | 1,000 sheets each (20 lb.paper) |
| Master Roll Capacity | 260 masters per roll (based on "LG" drum) |
| Master Eject Box Capacity | Approx. 30 masters |
| Counters | Master and paper (electric LCD display) |
| Power Source | 120V, 60Hz, 15A |
| Power Consumption | Master making: 90W Printing:Up to 170W (130 ppm) Standby: 29.8W Energy Saver Mode (Sleep): 8.1W TEC: 1.3 kWh/week* |
| Dimensions W x D x H | 50" x 26.8" x 26.4" (1,224 mm x 681 mm x 670 mm) (mainframe, with table and platen cover in operating position) |
| Weight | 152.1 lbs. (69.1 kg) (mainframe) |
| Special Features | Energy Saver Mode, A3 Paper Feed Mode, Fine Mode, Auto Shut-Off Mode, Retry Paper Feeding, Multiple Copy Mode (2-in-1), Economy Mode, Edge Erase, Memory (30) & Class (99) Mode, Skip Feed, User Codes (100 preset), Job Programs (9), Job Proofing, Security Mode |
Cabinet Type 45
ID: 52152
Color Drum Type 20
ID: 243024
Tape Dispenser Type 20
ID: 243084
PC Controller Network (Type 4545A) Embedded Type (Optional)
ID: 243217
